FOCUSED DESIGN
A
B
C
Super-cardioid large diaphragm condenser capsule focuses on the source, the drum.
Circuit designed for high-dynamic range and an output level that melds well with preamps.
Body designed to allow proper airflow but also reduce frequencies captured by the rear node.
BUILT FOR THE JOB
Each Tom Mic has a solid brass headframe and mildew-resistant dust filter to protect against stick hits, dust, and debris.
28
dB
OFF-AXIS REJECTION
Our bleed-blocking head design and dual-bias circuitry work together to provide Tom Mic with up to 28dB of off-axis rejection. This means crisp, clear tom sounds with far less cymbal bleed than a traditional dynamic or condenser microphone.
READY TO CAPTURE TOMS. ANYWHERE.
AT HOME
Pro sound and isolation straight into your interface.
IN THE STUDIO
The power of a condenser with better rejection than a dynamic.
ON THE ROAD
Studio sound and isolation, built for the rigors of touring.
ONBOARD SOUND SHAPING
Tom Mic’s filters impact the overall performance of the microphone and play a critical role in its sonic versatility.
Specifications
Type | Side-address pressure gradient FET condenser |
Capsule | 32mm |
Polar Patterns | Super-Cardioid |
Freq. Response | 20Hz-20KHz |
Dynamic Range
| 135dB minimum |
SPL Handling
| >135DB (0.5%THD@1000Hz) |
Impedance | >150 ohms |
Self-noise level
| < 15dB-A |
Signal-to-Noise Ratio
| 79dB |
Sensitivity | -58.0dBV/Pa (0dB=1V/Pa 1KHz) |
Connector | 3-pin XLR |
Power | Requires 48v Phantom Power |
Dimensions | 127 x 60mm (mic only) 131 x 106mm (with mount) |
Weight | 348g (mic only) 450g (with mount) |
DIAGRAMS
IN THE BOX
TOM MIC / ADJUSTABLE HARD MOUNT / CORDURA® MIC BAG
